Stryker EPIC II Service Manual

Return To Table of Contents
www.stryker.com 2030-809-002 REV D 83
Base Assembly, EPIC II
®
PLUS Steer Option - 2030-999-137 (Reference Only)
Item Part No. Part Name Qty.
EA 0003-349-000 Hex Head Cap Screw 1
EB 0025-191-000 Rivet 1
ED 0023-092-000 Truss Head Phillips Screw 4
EE 0030-052-000 Snap Bushing 2
EF 3006-200-380 Steer Extension Spring 1
EG 3006-200-378 Swivel Lock Return Spring, Right 1
EH 0045-008-000 O-Ring 1
EJ 0052-305-000 Flat Washer 1
EL 3000-200-337 Push Fit Ball Plunger 1
EM 3006-200-339 Steer/Swivel Lever Bushing 1
EN 3000-200-341 Steer Pedal Bushing 1
EP 0011-611-001 Washer 1
ER 3000-200-348 Washer 1
ES 3000-200-349 Washer 1
ET 3001-200-306 Brake Pedal Shaft Bearing 2
EU 3001-200-342 Steer Cable Assembly 1
EW 3006-200-381 Steer/Swivel Lever 1
EX 2030-200-001 Steer Pedal Assembly 1
EY 5000-090-013 Steer Label 1
Base Assembly and Options
