23,7 24 24,1 24,4 24,7
EN/06.2019/G57 © STULZ GmbH – all rights reserved
C7000 INSTRUCTIONS fOR a/C UNITS
Room temp. /°C
Fresh air/
exhaust air
louver
Compressor start
temperature
Compressor
MIX Mode
The MIX mode is enabled, when the fan has attained the maximum speed
1
.
In the MIX mode the compressor can be switched on according to its winter start temperature or the CW valve
can be opened according to its parameters. The ECO louvers (fresh air/exhaust air) are completely opened.
The fan runs with maximum speed
1
.
In units with speed-controlled compressor the MIX mode can also be triggered by the start of the speed-con-
trolled compressor, as the compressor is not locked during FC and EFC mode. When MIX mode is triggered
by the start of the speed-controlled compressor the fresh air louver will be opened 100% and the fan speed
will be increased to the maximum speed.
SP
DX Mode
DX mode is always chosen when at least one of the general enabling conditions for free cooling does not exist
anymore.
1
see Fan speed table
