108 EN/06.2019/G57 © STULZ GmbH – all rights reserved
C7000 INSTRUCTIONS fOR A/C UNITS
The corresponding commands:
6. Special operation modes
sets the timer stop mode for
monday from 12:00 to 12:59
Day: Hour: Status:
mo = monday 0 = from 0:00 to 0:59 0 = A/C unit off (timer stop)
tu = tuesday 1 = from 1:00 to 1:59 1 = A/C unit on with setpoint 1
we = wednesday 2 = etc. 2 = A/C unit on with setpoint 2
th = thursday
fr = friday
sa = saturday
su = sunday
Display in the main menu when the
timer program is executed:
The week timer is based upon two different temperature setpoints which you have
already adjusted in the menu "Operate/Values/Air/Temperature". Setpoint 1 is
represented by a "1", setpoint 2 by a "2".
The setting is user-friendly. Each digit represents an hour of the day. The week-
days are displayed in lines. With the selector key you can jump between the hours
of the day. At the end of a line the cursor jumps to the beginning of the next line.
With the OK key you modify the value of the digit where the cursor is placed. Three
values are possible: 0, 1 and 2. By pressing the OK key these values appear in
rising order and will then begin at "0" again.
By pressing the key combination selector key + OK key the value, on which the
cursor is placed, will be copied to the next digit (corresponding to the selected
direction of the selector key). This way you can easily adjust several hours or days.
For each hour of each day of the week you choose among three settings:
Display:
1. A/C unit off 0
2. A/C unit on with setpoint 1 1
3. A/C unit on with setpoint 2 2
6.1 Week program
wprg mo 12 0
Menu:
Config/Values/Week program
