171
Pin Bezeichnung
1 24VAC
2 GND
3 GND
4 Din 1
5 Din 2
6 Din 3
7 Din 4
8 Din 5
9 Din 6
10 Din 7
11 Din 8
12 Din 9
13 Din 10
14 Din 11
15 Dout 1 (NO)
16 Dout 1 (COM)
17 Dout 1 (NC)
18 Dout 2 (NO)
19 Dout 2 (COM)
20 Dout 2 (NC)
21 Dout 3 (NO)
22 Dout 3 (COM)
23 Dout 3 (NC)
24 Dout 4 (NO)
25 Dout 4 (COM)
26 Dout 4 (NC)
27 Dout 5 (NO)
28 Dout 5 (COM)
29 Dout 5 (NC)
30 Dout 6 (NO)
31 Dout 6 (COM)
32 Dout 6 (NC)
33 Dout 7 (NO)
34 Dout 7 (COM)
35 Dout 7 (NC)
Pin Bezeichnung
36 +15V
37 GND
38 Ain 1
39 Ain 2
40 +15V
41 GND
42 Ain 3
43 Ain 4
44 +Ub
45 GND
46 Ain 5
47 GND
48 Aout 1
49 GND
50 Aout 2
51 GND
52 Aout 3
53 GND
54 Aout 4
55 GND
56 Port 1H
57 Port 1L
58 Port 1H
59 Port 1L
60 +15V
X10 SUBD 15
X11 SUBD 15
X12 SUBD 15
X13 SUBD 15
X14 SUBD 15
X15 SUBD 9
© STULZ GmbH – all rights reserved EN/06.2019/G57
C7000 INSTRUCTIONS fOR a/C UNITS
Assignment - I/O controller
The assignment depends on the unit type.
Pin Designation Pin Designation
