Pin Bezeichnung
1 Din 12
2 Din 13
3 Din 14
4 Din 15
5 Din 16
6 Din 17
7 Din 18
8 Din 19
9 Dout 8 (NO)
10 Dout 8 (COM)
11 Dout 8 (NC)
12 Dout 9 (NO)
13 Dout 9 (COM)
14 Dout 9 (NC)
15 Dout 10 (NO)
16 Dout 10 (COM)
17 Dout 10 (NC)
18 Dout 11 (NO)
19 Dout 11 (COM)
20 Dout 11 (NC)
21 Dout 12 (NO)
22 Dout 12 (COM)
23 Dout 12 (NC)
24 Dout 13 (NO)
25 Dout 13 (COM)
26 Dout 13 (NC)
27 PWM1
28 GND
29 PWM2
30 GND
X10 SUBD 15
© STULZ GmbH – all rights reserved EN/06.2019/G57
C7000 INSTRUCTIONS fOR a/C UNITS
Assignment - EDIO board
The assignment depends on the unit type.
Pins 31 to 40 are not assigned.
Pin Designation
