C7000 Display
C7000 IOC
© STULZ GmbH – all rights reserved EN/06.2019/G57
C7000 INSTRUCTIONS fOR a/C UNITS
The C7000 display is connected to the C7000IOC by the RS232 service port. Connecting the C7000 display
to a bus is not possible.
Connection of the C7000 display to the C7000IOC
Service port
RS232
Service port
RS232
Part no. Designation Length
M26621 RS232 cable 1200mm
M26620 RS232 cable 1800mm
M26928 RS232 cable 3400mm
M26624 power supply cable 1500mm
M26622 power supply cable 2400mm
