Chapter 3 Maintaining the Sun Fire Servers 3-73
FIGURE 3-55 Designation and Speeds of PCI Slots – Sun Fire X4100/X4100 M2
FT1
FM0
FT1
FM1
FT1
FM2
FT0
FM0
FT0
FM1
FT0
FM2
CPU1 CPU0
Front panel
Back panel
PCIX1
(133-MHz)
PCIX0
(100-MHz)
01
FT1
FM0
FT1
FM1
FT1
FM2
FT0
FM0
FT1
FM1
FT1
FM2
CPU1 CPU0
Front panel
Back panel
PCIE1
(PCIE 8-lane)
PCIE0
(PCIE 8-lane)
01
Sun Fire X4100 M2
Sun Fire X4100
