Appendix E Connector Pinouts E-5
E.6 Serial Attached SCSI Connector
The Serial Attached SCSI (SAS) connector pins and their corresponding descriptions
are shown in the figure and table in this section.
FIGURE E-6 Serial Attached SCSI Connector
8 B_GND Blue video return (ground)
9 KEY No pin
10 S_GND Sync return (ground)
11 ID0 ID0 (no connect)
12 ID1/SDA MONID1
13 HSYNC Horizontal sync
14 VSYNC Vertical sync
15 ID3/SCL MONID2
TABLE E-5 VGA Video Connector Pinouts
Pin Number Pin Name Description
Signal segment
Power segment
Backside signal segment
Pin S1Pin S7
Pin P15 Pin P1
Pin S14 Pin S8
