Appendix E Connector Pinouts E-9
21 DVD_DDATA[3]
22 PS0_ENABLE_L
23 DVD_DDATA[13]
24 SAS_FAN_LED_L
25 DVD_DDATA[2]
26 PS0_VIN_GOOD
27 DVD_DDATA[14]
28 PS0_POWEROK
29 DVD_DDATA[1]
30 DVD_DDACK_L
31 DVD_DDATA[15]
32 DVD_DRDY
33 DVD_DDRQ
34 DVD_INT_L
35 DVD_DDATA[0]
36 GND
37 DVD_DIOR_L
38 SAS_DISK3_RX_P
39 DVD_DIOW_L
40 SAS_DISK3_RX_N
41 DVD_DADDR[1]
42 SAS_DISK1_RX_P
43 DVD_PDIAG_L
44 SAS_DISK1_RX_N
45 DVD_DADDR[0]
46 GND
47 DVD_DADDR[2]
48 SAS_DISK3_TX_P
49 DVD_DCS1_L
50 SAS_DISK3_TX_N
TABLE E-7 Flex Cable Motherboard Connector Pinouts (Continued)
Pin Number Signal Name
