E-10 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
51 DVD_DCS3_L
52 GND
53 DVD_DASP_L
54 SAS_DISK1_TX_P
55 +5V
56 SAS_DISK1_TX_N
57 GND
58 GND
59 SAS_DISK2_TX_N
60 +5V
61 SAS_DISK2_TX_P
62 GND
63 GND
64 GND
65 SAS_DISK2_TX_N
66 DISK3_ACT_LED_L
67 SAS_DISK0_TX_P
68 SPINDLE_ID0
69 GND
70 DISK2_ACT_LED_L
71 SAS_DISK2_RX_N
72 DISK1_ACT_LED_L
73 SAS_DISK2_RX_P
74 DISK0_ACT_LED_L
75 GND
76 SPINDLE_ID1
77 SAS_DISK0_RX_N
78 GND
79 SAS_DISK0_RX_P
80 PS_KILL
TABLE E-7 Flex Cable Motherboard Connector Pinouts (Continued)
Pin Number Signal Name
