Appendix E Connector Pinouts E-13
6 DD8
7 DD7
8 DD9
9 DD6
10 DD10
11 DD5
12 DD11
13 DD4
14 DD12
15 DD3
16 DD13
17 DD2
18 DD14
19 DD1
20 DD15
21 DD0
22 DMARQ
23 Ground
24 DIOR_L
25 DIOW_L
26 Ground
27 IORDY
28 DMACK_L
29 INTRQ
30 IOCS16_L
31 DA1
32 PDIAG_L
33 DA0
34 DA2
35 CS1FX_L
TABLE E-9 Flex Cable DVD-ROM Drive IDE Connector Pinouts (Continued)
Pin Number Signal Name
