F-4 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
Note – The screens shown in this appendix are examples. The version numbers and
the screen items shown are subject to change over the life of the product.
F.3.1 User Input Keys
The general key inputs that are listed in TABLE F-1 apply on all screens of the SAS
BIOS Configuration Utility.
F.3.2 Adapter List Screen
When you start the Fusion-MPT SAS BIOS Configuration Utility, the Adapter List
screen (shown below) appears.. This screen displays a scrolling list of up to 256 LSI
Logic SAS host adapters in the system and information about each of them.
TABLE F-2
describes the fields in this screen.
TABLE F-1 User Input Keys
Key Definition Description
F1 Help Context-sensitive help for the field in which the cursor is
positioned.
Arrow keys Move cursor Up, down, left, right movement to position the cursor.
Home/End Select item Select the item in which the cursor is positioned.
+/- Change item Items with values in [ ] brackets are modifiable. Numeric
keypad + and numeric keypad - update a modifiable field
to its next relative value.
Esc Abort/Exit The Esc key aborts the current context operation and/or
exits the current screen. The user is asked to confirm, if
changes have been made.
Enter Execute <item> Executable items are indicated by highlighted text and a
different background color. Press Enter to execute the
item’s associated function.
Throughout the GUI, selections that are not currently
permissible are grayed out.
The behavior of executable items varies throughout the
Configuration Utility.
