F-8 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
********************************************************************************
* LSI Logic MPT Setup Utility v6.02.00.00 (2005.07.08) *
* Adapter Properties -- SAS1064 *
* *
* Adapter SAS1064 *
* PCI Slot 00 *
* PCI Address(Bus/Dev/Func) 02:03:00 *
* MPT Firmware Revision 1.04.00.00-IR *
* SAS Address 50003BA0:000003BA *
* Status Enabled *
* Boot Order 0 *
* Boot Support [Enabled BIOS & OS] *
* *
* RAID Properties *
* *
* SAS Topology *
* *
* Advanced Adapter Properties *
* *
* *
* *
* *
* Esc = Exit Menu F1/Shift+1 = Help *
* Enter = Select Item -/+ = Change Item *
********************************************************************************
TABLE F-4 Adapter Properties Screen Field Descriptions
Field Description
Adapter The specific LSI Logic SAS controller type.
PCI Slot The PCI slot in which the controller is located.
PCI Address The PCI address assigned to the adapter by the system BIOS.
Bus value has range 0x00 - 0xFF, 0 - 255 decimal.
Device value has range 0x00 - 0x1F, 0 - 31 decimal.
Function has range 0x00 - 0x7, 0 - 7 decimal.
MPT Firmware
Revision
The Fusion MPT firmware version and type (IR or IT).
SAS Address The SAS Address assigned to this adapter.
