Chapter 1 Introduction 1-11
FIGURE 1-8 Sun Fire X4200 M2 Replaceable Component Locations
10 Fan connector boards (2) (not visible—underneath fan modules)
11 PCI-X card slot (1)
12 Graphics-redirect and service processor (GRASP) board
13 Motherboard
14 Battery
15 DIMMs (up to 4 for each CPU)
16 CPUs and heatsinks (2)
17 Front I/O board
18 Front panel indicator board
Figure Legend
2
7
14
8
16
10
9
17 1812
5
1513
11
3
4
1
