FIGURE 1-8 shows the locations of the Sun Fire X4200 M2 server replaceable
components, with the top covers removed.
Figure Legend
1 Rear fan tray
2 Power supplies (2)
3 Power distribution board
4 Flex cable (underneath cable retainer)
5 Hard disk drive backplane
6 PCIe card slots (4)
7 DVD-ROM drive
8 Hard drives (4)
9 Fan modules (6)
10 Fan connector boards (2) (not visible—underneath fan modules)
11 PCI-X card slot (1)
12 Graphics-redirect and service processor (GRASP) board
13 Motherboard
14 Battery
15 DIMMs (up to 4 for each CPU)
16 CPUs and heatsinks (2)
17 Front I/O board
18 Front panel indicator board
