F-22 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
F.3.11 Integrated RAID Configuration and Management
Screens
Integrated RAID configuration and management involves many screens, all of which
are accessed by selecting RAID Properties on the “Adapter Properties Screen” on
page 7.
■ If no RAID volumes are currently configured, you are asked to create a RAID
volume.
Link Error Settings • Invalid DWORDs: The number of invalid DWORDs that have been
received, outside of PHY reset sequences, since the last PHY Link
Error Reset. The count stops when it reaches the maximum value.
• Loss of DWORD Sync: The number of times, since the last PHY
Link Error Reset, that DWORD synchronization was lost and the
link reset sequence occurred. The count stops when it reaches the
maximum value.
• Running Disparity Errors: The number of DWORDs with running
disparity errors that have been received, outside of PHY reset
sequences, since the last PHY Link Error Reset. The count stops
when it reaches the maximum value.
• PHY Reset Errors: The number of times the PHY reset sequence has
failed, since the last PHY Link Error Reset. The count stops when it
reaches the maximum value.
Link Error Count Actual link error count values since the last PHY Link Error Reset.
The counts stop when they reach their maximum value.
Threshold Count Link error count threshold values. When a Link Error Count exceeds
a Threshold Count within the Threshold Time (secs), the Fusion-MPT
FW may reduce the link rate.
Threshold Time (secs) Time, in seconds, over which to apply Threshold Count. When a Link
Error Count exceeds a Threshold Count within the Threshold Time
(secs), the Fusion-MPT FW may reduce the link rate.
Reset Link Error
Counts
Press Enter to reset the Link Error Counts for this PHY or all PHYs.
This operation issues a PHY Link Error Reset - SAS IO Unit Control
Request Message.0
Note: When you press Enter, the following prompt appears:
Are you sure you want to reset Phy error counts?
Reset error counts for this Phy only
Reset error counts for all Phys
Cancel
TABLE F-9 PHY Properties Screen Field Descriptions (Continued)
Field Description
