F-30 Sun Fire X4100/X4100 M2 and X4200/X4200 M2 Servers Service Manual • August 2009
If you select Synchronize Array, Activate Array, or Delete Array, you are prompted to
confirm the choice by pressing Y for yes or N for no.
********************************************************************************
* LSI Logic MPT Setup Utility v6.02.00.00 (2005.07.08) *
* Manage Array -- SAS1064 *
* *
* Identifier LSILOGICLogical Volume 3000 *
* Type IM *
* Scan Order 2 *
* Size(MB) 69618 *
* Status Optimal *
* *
* Manage Hot Spare *
* *
* Synchronize Array *
* *
* Activate Array *
* *
* Delete Array *
* *
* *
* Esc = Exit Menu F1/Shift+1 = Help *
* Enter = Select Item *
********************************************************************************
TABLE F-12 Manage Array Screen Field Descriptions
Field Description
Identifier The identifier of the array.
Type The RAID type of the array.
Scan Order The scan order of the array.
Size(MB) The size of the array.
Status The status of the array.
Manage Hot Spare Press Enter to modify the array hotspare configuration. This field is
grayed out under the following conditions:
• The array is inactive.
• The array is at its maximum number of devices.
• Integrated Striping firmware is used. Striped arrays do not support
hotspares, so no modifications can be made to an array after it is
created.
