Sunrise Internet Box - Default Configuration for the Local Network (LAN); Default Configuration for the Local Wireless Network (WLAN)

Page 22
Sunrise Internet Box User Manual
2.5.2 Default configuration for the local network (LAN)
The following table details the values of the principal LAN parameters of your Sunrise Internet Box
(ETH1 to ETH4):
LAN characteristics
Value
State
PORT1 IP address
192.168.1.1/24
PORT2 IP address
PORT3 IP address
PORT4 IP address
BROADCAST, ARP, MULTICAST
--
Activated
Gateway
--
The LAN traffic is routed to your ISP
Sunrise
NAT/PAT
--
Activated
2.5.3 Default configuration for the local wireless network (WLAN)
The following table details the principal default WLAN parameters of your Sunrise Internet Box.
Characteristics (Wi-Fi)
Value
IP address
192.168.1.1/24
Enable Wireless
Box checked
SSID
The network names are printed on the Sunrise Internet
Box’s product label.
Channel
Auto
Security password
The initial password is printed on the Sunrise Internet
Box’s product label.
