LOWER UNIT 9-5
16. Remove the three bolts and the shift rod guide housing as-
sembly.
Account for the detent ball, the spring and the plate.
17. Remove the three bolts 1, then remove the shift cam hous-
ing 2.
Account for the dowel pins.
Dissasembly of propeller shaft components
1. Slide the propeller shaft away from the reverse gear 3 and
the bearing housing assembly 1.
Account for the reverse gear back-up shim 2 and the re-
verse gear thrust washer 4.
2. Remove the push rod 1 and the forward gear thrust washer
2.
3. Remove the spring 3 from the clutch dog shifter.
4. Using the special tool, push the dog pin 1 out of the clutch
dog shifter.
" 09922-89810: Shift pin remover
