Suzuki F6A - Hydraulic Mechanism and Control

185
2
ND
GEAR
Since N
i
> n
i
, the output rpm is slowed in relation to the input rpm.
Since the rotation of the sun gear was reverse in 1st gear, the front carrier was slowed to that extent, but in 2nd gear the
sun gear is fixed, so the slowing of the front gear is less than that in 1st gear. Accordingly, the output rpm is higher than in
1st gear.
Operating brake, clutch
Front Rear Input: front internal gear
Forward clutch:
connects input shaft and
front internal gear
2nd brake band: fixes sun
gear
Internal
gear
Fwd (N
i
rpm) Fwd (n
i
rpm) Output: front carrier
Carrier Fwd (N
c
rpm) Stop Input rpm N
i
rpm
Sun gear Reverse Output rpm n
c
rpm
INPUT SHAFT
FORWARD CLUTCH
FRONT INTERNAL GEAR
REAR INTERNAL GEAR
OUTPUT SHAFT
SECOND BRAKE
3
RD
GEAR
Since the output rpm of the front internal gear and the sun gear are the same, the front planetary unit rotates at one
body so that N
i
= N
c
, and the output shaft and input shaft are in a state direct connection.
Operating brake, clutch
Forward clutch:
connects input shaft and
front internal gear
Direct clutch: connects
input shaft and sun gear
Front Rear Input: front internal gear
Output: front carrier
Input rpm N
i
rpm
Output rpm n
c
rpm
N
i
= N
s
= N
c
Internal
gear
Fwd (N
i
rpm) Fwd (n
i
rpm)
Carrier Fwd (N
c
rpm) Fwd
(n
c
rpm)
Sun gear Fwd (N
s
rpm)
INPUT SHAFT
FORWARD CLUTCH
FRONT INTERNAL GEAR
REAR INTERNAL GEAR
OUTPUT SHAFT
DIRECT CLUTCH
