SVAN 973 User Manual – Appendixes
118
Table A.1. Control setting codes
Group name
Group
code
Code description
Unit type
U
U973 (read only)
Serial number
N
Nxxxx (read only)
Software version
W
Wyyy yyy - revision number (read only)
Calibration factor
Q
Qnnnn:c nnnn - real number with the value
of the calibration factor (-99.9  99.9)
c: 0 - left channel, 1 - right channel
Measurement function
M
M1 - LEVEL METER
M2 - 1/1 OCTAVE analyser
M3 - 1/3 OCTAVE analyser
M4 - DOSE METER
Range
R
R1 - LOW (LEVEL METER, 1/x OCTAVE)
R2 - HIGH (DOSE METER)
Read only
Filter type in profile n
F
F1:n - Z filter for profile n
F2:n - A filter for profile n
F3:n - C filter for profile n
SLM, 1/1OCTAVE, 1/3OCTAVE, functions:
n: 1, 2, 3 – Profile Number: 1, 2 or 3
DOSE functions:
n: 4, 5, 6 – Profile Number: 1, 2 or 3
Peak Filter type in profile n
J
J1:n - Z filter for profile n
J2:n - A filter for profile n
J3:n - C filter for profile n
SLM, 1/1 OCTAVE, 1/3 OCTAVE RUNNING LEQ
functions:
n: 1, 2, 3 – Profile Number: 1, 2 or 3
DOSE function:
n: 4, 5, 6 – Profile Number: 1, 2 or 3
Detector type in profile n
C
C0:n - IMPULSE detector in profile n
C1:n - FAST detector in profile n
C2:n - SLOW detector in profile n
SLM, 1/1 OCTAVE, 1/3 OCTAVE functions:
n: 1, 2, 3 – Profile Number: 1, 2 or 3
DOSE function:
n: 4, 5, 6 – Profile Number: 1, 2 or 3
Filter type in 1/1 OCTAVE analysis and
1/3 OCTAVE analysis
f
f1 - Z filter
f2 - A filter
f3 - C filter
Logger type in profile n
B
Bx:n - x - sum of the following flags
flags:
