Teac TD-9000T User Manual

59
4-6-4-2-3. Peak
The load peak is held when measurement values are in the zone.
OFF
ON
HI
OFF
ON
LO
Load
Judgment output (load/displacement)
Zone interval
Hold point
Time or displacement
Measurement value
Internal hold value
Judgment output (load/displacement)
If the hold point meets a HI or LO condition, this becomes ON.
If the hold point is within the management value range, judgment for this zone will be OK.
4-6-4-2-4. Bottom
The minimum (bottom) load value is held when measurement values are in the zone.
OFF
ON
HI
OFF
ON
LO
Load
Judgment output (load/displacement)
Zone interval
Hold point
Time or displacement
Measurement value
Internal hold value
Judgment output (load/displacement)
If the hold point meets a HI or LO condition, this becomes ON.
If the hold point is within the management value range, judgment for this zone will be OK.
