3 - Technical Data
Introduction
Fig. 3-4 Freedom EVO version with Te-Stack base units in front position
Fig. 3-5 Freedom EVO version with Te-Stack base units in rear position
A
B
C
D
D
A Stacker column
B Te-Stack base unit
C Base unit support (front)
D Acrylic glass cover
A
B
C
D
D
D
A Stacker column
B Drawer
C Base unit support (rear)
D Acrylic glass cover
