CROSS PERSONAL: Service & maintenance manual - rev. 1.1
Page 2.11
CU618: Display Power supply & signals cable
(Patch conn. – CPU board – ON/OFF button)
Patch Conn.
CN1
Signal Colour
CPU
CN17
CPU
JP10
ON/OFF
button
1 485 –signal
Green
Twisted cable
6
2 485 + signal
Yellow
Twisted cable
12
3
Gnd
Black
1
4
+12Vdc power supply
Red
7
5
+12Vdc (ON/OFF)
White
1
6
Relay control(ON/OFF)
Brown
2
7
Remote OFF (ON/OFF)
Green
3
8
Gnd (ON/OFF)
Yellow
4
-
Gnd.
Yellow/green
5
Faston
CU619: Display Power supply & signals cable
(Patch conn. – Brake board – Power Supply board)
Patch Conn.
CN1
Signal Colour
Brake Board
CN3
Power supply
board
P3
1 485 –signal
Green
Twisted cable
5
2 485 + signal
Yellow
Twisted cable
1
3
Gnd
Black
2
4
+12Vdc power supply
Red
6
5
+12Vdc (ON/OFF)
White
1
6
Relay control(ON/OFF)
Brown
2
7
Remote OFF (ON/OFF)
Green
3
8
Gnd (ON/OFF)
Yellow
4
CU620: High Voltage cable
(Power entry module – Patch connector)
Power entry
module
Signal Colour Patch conn.
Faston (F)
Line
Brown
Commercial
connector
Faston (N)
Neutral
Blue
Faston (T)
Earth
Yellow/green
