CU621: High Voltage cable
(Patch connector – Power Supply board)
Patch conn. Signal Colour
Power supply
Board
K1
Commercial
connector
Line
Brown
1
Neutral
Blue
3
Earth
Yellow/green
5
CU622: High Voltage cable
(Patch connector – Power Supply board)
Power supply
board
P2
Signal Colour
Brake board
CN4
1
Line
Brown
3
5
Neutral
Blue
1
3
Earth
Yellow/green
5
CU623: Cavo Freno
(Scheda Freno – Freno – Sensore velocità)
Scheda Freno
CN2
Signal Colour Brake
Speed
sensor
1
Power Supply Brake +
Brown
Faston
2
Power Supply Brake -
Blue
Faston
3
RPM signal
Yellow
Faston
4
Gnd. RPM
Black
eyelet
CU471: HR Cardio Receiver cable
(CPU Board – HR Cardio Receiver)
CPU Board:
CN23
Signal Colour
HR Cardio
Receiver: CN1
1
+5 Vdc power supply
White
2
7
Pulse (beat to beat)
Black
4
8
Gnd
Green
1
