CROSS PERSONAL: Service & maintenance manual - rev. 1.1
Page 6.31
P – N (phase – neutral) = 220Vac / 110 Vac
P – G (phase – ground) = 220Vac / 110 Vac
N – G (neutral – ground) = 0 Vac
(4) Check that:
a. The faston of the cable are well connected to the Hand Sensor plates;
b. The signal continuity of the CU616 cable, which connect the HS plates to the HD3&2
connectors on the receiver, using a tester and referring to the paragraph: 2.10.
“Cables”;
c. There is NO continuity between the Hand Sensor plates and the ground faston on the
receiver (otherwise the signal are grounded).
