RUN 600 XTPRO: Service & Maintenance Manual - rev. 1.3
Page 2.5
RX-6: Elevation motor cable
Elevation board – Elevation motor – Limit Switches
Elevation board
CN3
Signal Color Elevation
motor
Upper
LS
Lower
LS
1 Motor power supply Brown 1 - -
2 Motor ground Blue 2 - -
3 NO upper limit White - 3 -
4 NC lower limit switch Violet - - 2
6 Limit switch ground Black - 1 1
RX-8: Low voltage power supply cable
Power supply – Inverter interface board
Power supply
CN2
Signal Color Inverter interface
board
CN4
1 +12 Vdc Red 2
3 +5 Vdc Yellow 4
4 Ground Black 3
6 -12 Vdc Blue 1
RX-11: Elevation motor power supply cable
Elevation board – Rectifier bridge
Elevation board
CN6
Signal Color Rectifier bridge
1 48 VAC Red +
2 Ground Black
−
RX-12: Photocell cable
Elevation board – Photocell
Elevation board
CN1
Signal Color Photocell
1 +5 Vdc Red 1
2 Clock Orange 2
3 Direction Blue 3
4 Ground Black 4
