RUN 600 XTPRO: Service & Maintenance Manual - rev. 1.3
Page 2.7
CR-XT: Non coded heart rate meter cable
CPU board – Cardio receiver
CPU board
CN4
Signal Color Receiver
1 +5 Vdc Red 1
2 Pulse per beat Blue 2
6 Ground Black 3
RX-4FR: Hand sensor cable
CPU board – HS interface board
CPU board
CN7
Signal Color HS interface
board
HD4
1 Pulse per beat Blue 3
2 Ground Black 1
4 +5 Vdc Red 2
RX-HS1UL: Sensor cable
HS interface board – Sensor
HS interface
board
HD2-HD3
Signal Color Sensor
1 Signal Black Faston
2 Signal reference Clear Faston
3 Shield Black -
