RUN 600 XTPRO: Service & Maintenance Manual - rev. 1.3
Page 7.8
Figure 7.5-6
9. Rotate the RECEIVER support.
10. Remove the RECEIVER by pulling it from
the top.
Figure 7.5-7
11. Disconnect connector e.
12. Remove the RECEIVER.
To reassemble the RECEIVER, carry out the
above steps in reverse order.
WARNING: route the cables as described in paragraph 11.1. “Technical notes on cardio
receivers”.
