SYNCHRO EXCITE 2009: Service & maintenance manual - rev. 5.2
Pagina 9.32
9.5.1.4. Table of configuration parameters
To correctly display the parameter values, you need to load them from the low kit, using the
“Read from low kit” function.
To change the setting, press the CHANGE key and insert the value using the numeric keyboard.
Press ENTER key to confirm or BACK key to back forward.
After any changes to the parameter values, you need to load them in the low kit using the
“Write to low kit” function.
Speed ratio (integer part)
Minimum braking current (standby pos.) [mA]
Maximum continuous power [W]
Machine torque correction coefficient (constant torque)
User friction torque
Maximum coil temperature [°C]
Minimum revolutions [RPM]
Speed ratio (decimal part)
User friction torque delta
Press HOME to confirm and save, FORWARD or BACK to scroll the pages.
