SYNCHRO EXCITE 2009: Service & maintenance manual - rev. 5.2
Page 4.1
4. ACCESSORIES
4.1. CARDIO THEATER CONNECTION
The machine can be connected to the CardioTheater by means of the RJ45 connector on the CSafe
board. The CardioTheater unit must be provided with a power cable having the following pin-out:
5 +5 Vdc
WARNING: for the numbering of the pins, on RJ45 connector, please refer to the diagram
below:
