6.3. THE DISPLAY FAILS TO ILLUMINATE
This error occurs when the power supply voltage is not reaching the upper assembly.
6.3.1. 500 AND 700 MODELS
Does the wall outlet supply the
correct voltage?
Is the mains lead OK?
Are the LEDs on the
Display board lit on?
Plug the machine into a
working electrical outlet
Replace the mains lead
Replace the Display
board
THE DISPLAY
DOES NOT
ILLUMINATE
NO
YES
NO
YES
NO
YES
A
1
Are the fuses OK?
Replace the fuses
YES
NO
Continued on the following page
