SYNCHRO EXCITE 2009: Service & maintenance manual - rev. 5.2
Pagina 6.18
6.6. NO TV PICTURE
Check that the machine is connected to an antenna signal
This error can be due to an incorrect machine configuration, or to problems with the antenna signal.
NOTE ONLY FOR JAPAN: Before to carry out the following troubleshooting, check that the
B-CAS card is correctly inserted on the TV Digital Board.
NO TV PICTURE
Check if the antenna cable is
properly connected
Connect the cable
NO
1
On the other machines y ou see
the TV?
Check the antenna
signal.
NO
Connect the machines at one
antenna soket sure working.
Replace the antenna
soket
NO
A
YES
YES
Continued on the following page
To Next Page
