Technogym SYNCHRO EXCITE 2009 - ELT Cables

SYNCHRO EXCITE 2009: Service & maintenance manual - rev. 5.2
Pagina 2.14
CU169: Display power supply cable
(CPU board – Digital TV board – Patch conn.)
Patch connn.
Signal Colour
CPU board
CN20
Digital TV board
J1
1
GND
Yellow/Green
1
-
2
GND 12Vdc
Black
2
-
3
GND 5Vdc
Black
-
2
4
sensing GND 5Vdc
Black
-
4
5
n.c.
-
-
-
6
+12Vdc
Red
6
-
7
+5 Vdc
Red
-
1
8
sensing + 5Vdc
Red
-
3
CU240: LCD inverter power supply cable
(CPU Board – Inverter LCD)
CPU board
CN5
Signal Colour
LCD Inverter
CN1
1
Input voltage + 12 Vdc
Black
1
5
Input voltage + 12 Vdc
Black
2
2
GND
Black
3
4
GND
Black
4
3
Power system return
:
5Vdc = ON
0Vdc = OFF
Black 5
7
n.c.
Black
6
6
Lamp control
Black
7
2.8.4. ELT CABLES
ELT-00: High voltage cable
(Power entry module – Brake board
Power entry module Signal Colour
Brake board
CN4
F
Line
White
1
N
Neutral
Black
3
T
Earth
Green
5
