SYNCHRO EXCITE 2009: Service & maintenance manual - rev. 5.2
Page 2.15
ELT-01: Alternator cable
(Brake board – Alternator – Battery – Inlet for battery charging)
Brake board
CN3
Signal Colour Alternator Battery
Battery charging
inlet
1
V+ voltage from
alternator
Red
Faston
-
2
V- voltage from
alternator
Black
Faston
-
3
RPM signal
White
Faston
4
V+ voltage from
battery charger
Red
-
soldered to internal
contact
5
V- voltage from
battery charger
Black
-
soldered to external
contact
6
Battery V+
Red
-
Faston
-
7
Battery V-
Black
-
Faston
-
ELT-02: Brake supply cable
(Brake board – Brake – Speed sensor)
Brake board
CN2
Signal Colour Brake Speed sensor
1
Brake supply +
Brown
Faston
-
2
Brake supply -
Blue
Faston
-
3 SPM Grey -
Faston connected to
brown cable
4
SPM Reference
Black
-
eyelet
5
-
-
-
-
6
-
-
-
-
ELT-04: Power supply cable between upper and lower assemblies
(Brake board - Patch connector 1)
Brake board
CN1
Signal Colour
Patch connector
1
2
Gnd
Blue
2
3
Gnd
Red
3
4
- sensing +5 Vdc digital
Black
4
6
+12 Vdc
White
6
7
+5 Vdc
Green
7
8
+sensing +5 Vdc digital
Orange
8
