2.8. WIRING
The connectors indicated in the following pages, refer to 700 model’s LED Boards, unless
otherwise indicated.
The colour of the cables can be changed, refer in particular to the Pin Out.
2.8.1. CBQ CABLES
CBQ-13: CSafe board cable
(Display Board – CSafe Board)
Display Board
CN8
Signal Colour
CSafe Board;
CN1
1
Digital #1
Flat cable
1
…
…
…
…
14
Digital #14
Flat cable
14
CBQ-32: TGS Cable
(Display Board/CPU Board – Patch connector)
Display Board:CN7
CPU Board:CN8
Signal Colour Patch conn.
1
+12 Vdc power supply
Rosso
8
3
Rx
Marrone
1
5
Tx
Blu
2
9
Gnd
Nero
6
2.8.2. CB CABLES
CB-9: DVD video input cable
(Connectors Board –Input AUX Board)
Scheda connettori
CN1
Segnale Coloure
Scheda input
J2
1
Color
Red
1
2
left audio IN
White
2
3
Gnd
Braid
3
4 right audio IN Red 4
5
Gnd
Braid
5
6
video IN
Yellow
6
7
Gnd
Braid
7
8
Switching
White
8
