ELT-23: Handlebar sensor cable
(Patch connector 5 – Sensors)
Patch
connector
Signal Colour
Sensors
rh 1
rh 2
lh 1
lh 2
1
Gnd
Braid
-
-
-
-
2
Sensor signal reference
Black
-
-
down
down
3
Left sensor signal
White
-
-
up
up
4
Gnd
Braid
-
-
-
-
5
Sensor signal reference
Black
down
down
-
-
6
Right sensor signal
White
up
up
-
-
ELT-31: Hand sensor board cable - Lever buttons
(Patch conn. 6 - Hand sensor board - Lever connectors - Connector Board)
Patch
connector
6
Signal Colour
Hand Sensor
Board
J3
Lever
connector
Connector
board
RH
LH
J2
J4
8
+ 5Vdc Power supply
Red
4
-
-
-
-
7 NA Green 1 - - - -
1
NA
Orange
2
-
-
-
-
3
Out pulse
Blue
5
-
-
-
-
2
Reference
Black
3
-
-
-
-
12
+ 5Vdc Power supply
White
-
-
6
-
-
11
Left lever button signal
(–)
Brown
-
-
3
-
-
10
Reference
Green
-
-
5
-
-
-
Gnd
Braid
-
-
2
1
-
-
Reference
Black
-
-
4
2
-
-
Left sensor signal
Clear
-
-
1
3
-
6
+ 5Vdc Power supply
White
-
6
-
-
-
5
Right lever button signal
(+)
Brown
-
3
-
-
-
4
Reference
Green
-
5
-
-
-
-
Gnd
Braid
-
2
-
-
1
-
Reference
Black
-
4
-
-
2
-
Right sensor signal
White
-
1
-
-
3
