SYNCHRO EXCITE 2009: Service & maintenance manual - rev. 5.2
Pagina 6.20
Follow the procedure step by step to correctly diagnose the problem. Take particular care with the
checks highlighted by circled numbers, which are described in detail below:
(1) Check that the antenna cable is correctly connected to the TUNER on Digital TV board.
(2) Carry out the the configuration procedure as detailed at paragraph 9.5.6. “TV Standard”.
(3) Chech that the antenna signal matches with the minimal requested specifications detailed at
paragraph: 5.2. “Installation requirements and specifications for Wellness TV machines”.
(4) Verificare lo stato del cavo antenna CU-198, che sia funzionante ed in buono stato.
If you replace Display board/Brake board, check that its SW version is updated, otherwise
install the last version.
The TV and RADIO channels is located in the Digital TV in the CPU Board and must
necessarily be present. This means that when even one of the two boards will be replaced,
should be re-stored channels through search or transferring from another machine via TGS
key or cable transfer.
