6-11
Model 3550 LCR Meter Instruction Manual Service Information
Model 3550 Verification Procedure cont’d:
TEGAM 3550 AND AGILENT 4284A MEASUREMENTS
A B A-B
STANDARD
VALUE
FREQ
(Hz)
LEVEL
(V)
PARAMETER 4284A 3550 ERROR TOL.
(CTS)
.1µF 100k 1 LJ =(A-B) *100 187
.01µF 10k 1 Z =(A-B) *10k 33
.01µF 10k 1 LJ =(A-B) *100 28
.1µF 10k 1 Z =(A-B) *100 26
.1µF 10k 1 LJ =(A-B) *100 20
1µF 10k 1 Z =(A-B) *1k 96
1µF 10k 1 LJ =(A-B) *100 86
.01µF 100k 1 Z =(A-B) *100 83
.01µF 100k 1 LJ =(A-B) *100 78
.1µF 100k 1 Z =(A-B) *1k 203
1µF 100k 1 Z =(A-B) *10k 425
1µF 100k 1 LJ =(A-B) *100 341
.01µF 1M 1 Z =(A-B) *1k 203
.01µF 1M 1 LJ =(A-B) *100 187
.1µF 1M 1 Z =(A-B) *10k 525
.1µF 1M 1 LJ =(A-B) *100 531
1Mƻ 1k 1 LJ =(A-B) *10k 180
1Mƻ 1k 1 Z =(A-B) *100 23
10Mƻ 1k 1 LJ =(A-B) *1k 235
10Mƻ 1k 1 Z =(A-B) *100 44
100Mƻ 1k 1 LJ =(A-B) *100 1015
100Mƻ 1k 1 Z =(A-B) *100 426
NOTE: Phase values are dependent on the phase of the device under test. If the Standard is beyond .1
degree in phase for resistance values the tolerance must be recalculated. Exceptions are 1M ohm and 10M
ohm, which should be within 2 degrees and 100M ohm, which should be within 5degrees.
TEGAM 3550 AND AGILENT 4284A MEASUREMENTS
A B A-B
STANDARD
VALUE
FREQ
(Hz)
LEVEL
(V)
PARAMETER 4284A 3550 ERROR TOL.
(CTS)
10kƻ 1M 1 Z =(A-B) *1k 205
10kƻ 1M 1 LJ =(A-B) *100 71
100kƻ 1M 1 Z =(A-B) *100 605
100kƻ 1M 1 LJ =(A-B) *100 183
100ƻ 5M 1 Z =(A-B) *100 355
100ƻ 5M 1 LJ =(A-B) *100 153
1kƻ 5M 1 Z =(A-B) *10k 655
1kƻ 5M 1 LJ =(A-B) *100 353
NOTE: Phase values are dependent on the phase of the device under test. If the Standard is beyond 1 degree in phase for
resistance values the tolerance must be recalculated.
