C LEAR P ATH U SER M ANUAL R EV . 1.97 93
M OUNTING D IMENSIONS : C LEAR P ATH NEMA 23
32
1.260
32
1.260
4x
3.18
.125
For #6 or M3
Thread-Cutters
For mounting 40mm Fan
USB Access
L
[ 2.54 ]
L
[ .100 ]
1.90±0.10 .075±.004
37.68 1.483
9.53
-
0 0.01
.3750
+
-
.0000 .0005
3
.118
20.58±0.76
.810±.03
3
.118
12
.472
44.45 1.750
10.82
.426
Recommended Clearance for USB Access
59.10±0.76 2.327±.030
38.10
-
0 0.13
1.500
+
-
.000 .005
4x
5.20
.205
THRU
53.85 2.120
81.85±0.76
3.222±.03
66.68
2.625
I/O Connector
Power Connector
6.35
.250
Optional 1/4" Full Round Shaft
Model Number
L
CPM-_ _ _ _ -2310_ - _ _
[84.81] 3.339
CPM-_ _ _ _ -2311_ - _ _
[84.81] 3.339
CPM-_ _ _ _ -2321_ - _ _
[103.83] 4.088
CPM-_ _ _ _ -2331_ - _ _
[122.83] 4.836
CPM-_ _ _ _ -2341_ - _ _
[141.83] 5.584
23XX ClearPath Motor Family
20.58±0.76
.810±.03
T
EKNIC , I NC . F AX (585)784-7460 V OICE (585)784-7454
