C
LEAR
P
ATH
U
SER
M
ANUAL
R
EV
.
1.97
85
C
LEAR
P
ATH
h replace stepper motor/drive
nit. While all ClearPath SD models
solution
S
TEP AND
D
IRECTION
I
NPUT
SD
(S
TEP AND
D
IRECTION
)
Clear ath SD family was designed toT e P
combos with a single, cost-effective u
function in essentially the same way, there are differences in re
and power between models within the family. See the Teknic/ClearPath
website for complete information on SD Family ClearPaths.
M
ODE
S
UMMARY
You provide standard step and direction signals and ClearPath faithfully
follows them. Use the included RAS (Regressive Auto Spline) feature to
smooth the motion profile. This mode is great for replacing stepper motor
and drive systems with one compact device that costs less and does more.
H
OW IT
W
ORKS
Assert the Enable Input to energize the motor. Then, supply standard step
and direction pulses to Inputs A and B to command motion. This model
requires step and direction signals from an external indexer, controller, or
similar.
Signal Function Input Type
Input A
Motor velocity vs. time
Input B
Enable
Direction
Step
Enable
NA NATrigger
Logic: High=CW Low=CCW
Pulse: Digital Step Input
Logic: High=Enable Low=Disable
0
1
0
1
t
v
Example Timing
Notes: Maximum pulse input frequency = 500 kHz.
Minimum pulse on/off time = 1uS.
0
1
0
1
Step and Direction Input Control
Stepper Replacement
Step and Direction Inputs and Timing
Notes:
• Maximum pulse input frequency = 500 kHz.
• Minimum pulse on/off time = 1uS. See diagram next page for
step and direction timing information.
• Motion occurs on the rising edge of each step input pulse.
• Time before Disable = 10 mS
T
EKNIC
,
I
NC
.
F
AX
(585)784-7460
V
OICE
(585)784-7454
