C
LEAR
P
ATH
U
SER
M
ANUAL
R
EV
.
1.97
27
U
SER
S
OFTWARE
(C
LEAR
P
ATH
MSP)
S
ECTION
O
VERVIEW
This section includes the following topics:
• ClearPath MSP System requirements
• Installing ClearPath MSP software
• Communicating with ClearPath
• Tour of ClearPath MSP
• Overview: Advanced Features
M
INIMUM
S
YSTEM
R
EQUIREMENTS
Operating System: Win XP SP3 or later, Win 7
Processor: 1 GHz or faster
Memory: 512 MB
HD Free Space: 512 MB
Monitor: 1280 x 1024 pixels or higher
Other: Sound card with speakers (optional)
I
NSTALLING
MSP
Launch the MSP installer and follow the on-screen prompts. Please
contact Teknic if you have problems with software installation.
C
OMMUNICATING
W
ITH
C
LEAR
P
ATH
After ClearPath MSP is installed on your PC, follow the directions below to
establish a communication link between your ClearPath and PC.
Note: g Establishing a ClearPath communication link is required for settin
operationa ning the l modes, defining move parameters and options, tu
motion system, and using the MSP Scope to analyze system performance.
OR
C
OMMUNICATION
S
ETUP
• A ClearPath Motor
I
TEMS
R
EQUIRED F
• A USB cable (Type A to Micro-B)
• A DC power supply (24–75VDC nominal) and cable
• A PC running Windows XP or Windows 7 with ClearPath MSP
installed
T
EKNIC
,
I
NC
.
F
AX
(585)784-7460
V
OICE
(585)784-7454
