F OLLOW D IGITAL T ORQUE C OMMAND (F REQUENCY I NPUT )
M ODE SUMMARY
Connect a digital variable frequency waveform from your PLC or other
device, and ClearPath will produce torque that is proportional to the
frequency of the waveform.
H OW IT W ORKS
Assert the Enable Input to energize the motor. Control torque by applying
a variable frequency pulse train to Input B. Pulse frequency is
proportional to commanded torque. Direction in which torque is applied
(CW/CCW) is controlled by the state of Input A. See Inputs and Timing
table below.
Signal Function Input Type
Input A
Motor torque vs. time
Input B
Enable
Direction
Torque
Enable
NA NATrigger
Logic: High=CW Low=CCW
Pulse: Variable Frequency
Logic: High=Enable Low=Disable
0
1
0
1
t
tq
Example Timing
Notes:
0
1
0
1
Variable Torque With Frequency Input Control
Torque Control
Variable Torque Mode g Diagram
Notes:
ue
• Disable time = 10 mS
(Frequency Control): Inputs and Timin
• Input frequency range: 20 Hz to 500 kHz.
• If the frequency signal is off for 50mS or more the input is
considered off. This is interpreted by ClearPath as a zero-torq
command.
