C
LEAR
P
ATH
U
SER
M
ANUAL
R
EV
.
1.97
20
C
ONNECTING
I/O
TO A
C
LEAR
P
ATH
M
OTOR
ClearPath I/O allows the user to send and receive control signals from a
ClearPath motor. There are a total of three digital inputs and one d
output accessible through the 8-position Molex MiniFit Jr. connector.
Refer to the diagram belo
igital
w for a list of I/O connector mating parts readily
available through most electronic component suppliers.
Clearpath I/O Features
5-24VDC compatible
Digitally filtered
Optically isolated
Configurable output
Many input options
I/O Connector
1234
8765
4 Enable +
8 Enable -
3 Input A+
7 Input A -
2 Input B +
6 Input B -
1 HLFB (output) +
5
HLFB (output) -
Connector Housing 8 position
Molex/39-03-9082 (black)
Terminals 22-28 AWG
Molex/39-00-0047 (loose)
Molex/ 39-00-0046 (reel)
Crimp Tool 16-24 AWG
Molex/63819-0900
Terminal Extractor Tool
Molex/11-03-0044
Mating Parts
I/O Connector Pinout
Cable Stock 8/22AWG
Belden 9421
ClearPath I/O connector and mating parts
C
LEAR
P
ATH
I
NPUTS
, and Input B, are designed
for use with 5-24VDC
1
logic levels and pulses from a wide variety of signal
sources and devices including PLCs, microcontrollers, and even simple
switch and battery rigs (with no external resistors required). They are
optically isolated, digitally filtered, current limited, and reverse polarity
protected for robust, long-term performance.
The three inputs, designated Enable, Input A
Enable+
Enable-
4
8
Input A+
Input A-
3
7
Input B+
Input B-
2
6
Current
Limiter
Current
Limiter
Current
Limiter
5-24
VDC
5-24
VDC
5-24
VDC
ClearPath Internal
External Circuit
+
+
+
ClearPath Inputs shown with simple switch and battery inputs
1
5-24VDC just means ClearPath will work with logic signal sources where logic “low” is 0VDC
while logic “high” can be any value between 5VDC and 24VDC inclusive.
T
EKNIC
,
I
NC
.
F
AX
(585)784-7460
V
OICE
(585)784-7454
