C
LEAR
P
ATH
U
SER
M
ANUAL
R
EV
.
1.97
105
P
ART
N
UMBER
K
EY
A
PPENDIX
F:
CPM
SDSK 34 P
---
1ELN1
Teknic Product Identifier
ClearPath Family/Model
Motor Frame Size
23 = NEMA 23 frame size
34 = NEMA 34 frame size
MCPV = Motion Controller/Position, Velocity, Torque Modes
MCVC = Motion Controller/Velocity, Torque, 2 Position Modes
SDSK = Step and Direction/“Stepper Killer” (Typically 3x power of similar sized steppers)
SDHP = Step and Direction/High Power model
Approximate Body Length (excludes shaft length)
1 = 82 mm
2 = 100 mm
3 = 120 mm
4 = 140 mm
Winding/Magnetic Structure
Indicates specific winding design
Note: Different designs offer different torque, speed, and power characteristics.
Motor Winding Type
S = Series-Wye (higher torque, lower speed)
P = Parallel-Wye (in between S and D characteristics)
D = Parallel-Delta (higher speed, lower torque)
Shaft Seal
N = Standard dust sealing
S = Extra Vyton seal, for environments with strong abrasives, such as fiberglass, or where liquid exposure may occur
Note: Seal option S not available for 1/4” shaft diameter models.
Motor Shaft Diameter
L = Standard shaft diameter
Note: Standard diameter is 1/2” for NEMA 34 models and 3/8” for NEMA 23 models.
Q = 1/4” shaft diameter
Note: Q option available only on NEMA 23, 1 and 2 stack motors.
Enhanced Options
R = Positioning Resolution of 800 counts per revolution; Standard selection of RAS settings.
E = Positioning Resolution of 6400 counts per revolution; Extended selection of RAS settings.
Note: MCVC available in R only. SDHP available in E only.
Note: All ClearPath models feature an internal encoder resolution of 12,800 counts per revolution.
CPM = ClearPath Motor.
Note: All ClearPath part numbers begin with CPM.
T
EKNIC
,
I
NC
.
F
AX
(585)784-7460
V
OICE
(585)784-7454
