C LEAR P ATH U SER M ANUAL R EV . 1.97 100
A PPENDIX C: C LEAR P ATH C ABLE P INOUTS
ns pinout information for ClearPath accessory cables
CPM-CABLE-CT
This section contai
available through Teknic and Teknic distribution.
RL-MU120
Cable description: ClearPath I/O connector cable. Overmolded Molex
MiniFit Jr. 8-position connector to standard MiniFit Jr. 8-position
connector (no over-mold on one end for easy access to wires).
wire entry view
5 - RED 8 - ORG
4 - BLU
3 - WHT
2 - BLK
1 - GRN
7 - BRN 6 - YEL
122"
Pin Assignments
Pin Color Name
1 GRN
2
3
4
5
6
7
8
BLK
HLFB +
Input B +
Input A +
Enable +
Input B -
Input A -
Enable -
HLFB -
WHT
BLU
RED
YEL
BRN
ORN
Factory
overmolded
connector
Standard
connector
CPM-CABLE-CTRL-MM660
Cable description: ClearPath I/O connector cable (double-ended).
Molex MiniFit Jr. 8-position connector to same. Use “as is” or cut in half
to make two cables with flying leads.
wire entry view
5 - RED 8 - ORG
4 - BLU
3 - WHT
2 - BLK
1 - GRN
7 - BRN 6 - YEL
662"
Pin Assignments
Pin Color Name
1 GRN
2
3
4
5
6
7
8
BLK
HLFB +
Input B +
Input A +
Enable +
Input B -
Input A -
Enable -
HLFB -
WHT
BLU
RED
YEL
BRN
ORN
