Section 8: Use the 4200A-CVIV Multi-Switch 4200A-SCS Parameter Analyzer User's Manual
8-6 4200A-900-01 Rev. D/April 2020
Add an action to perform CVU compensation
The cvu-cviv-comp-collect action configures the 4200A-CVIV to the selected channel
configuration and performs compensation.
To add an action:
1. Select Actions.
2. To find the action, enter cviv into the search bar, then select Search.
3. Select the cvu-cviv-comp-collect action.
4. Select Add to copy it to the project tree.
Configure the action
To configure the action:
1. Choose Configure.
Figure 108: Configure highlighted
