Section 5: Configure and use a Series 700 Switching System 4200A-SCS Parameter Analyzer User's Manual
5-8 4200A-900-01 Rev. D/April 2020
10. From the configuration navigator, select the switching system you just added (MTRX1).
11. In the Properties pane, add the 7072 Matrix Card to the correct slot of the switching system.
12. Confirm that the GPIB Channel of your device (0 to 30) matches the channel shown in the
Properties. The next figure shows a Keithley Instruments 707/707A/707B Switching System with
the matrix card installed in slot 1.
Figure 58: Properties pane of Keithley 708/708A/708B Switching System with one 7072 Matrix
Card
If you are using a 707B or 708B Switching System, you must use the control panel on the front of
your switching system to enable DDC and change the command set to 70XA by following these
steps:
1. Select Menu.
2. Select DDC.
3. Select Enable.
4. Select 70XB-VERSION.
This allows the switching system to be controlled by the 4200A-SCS.
