Tektronix MSO70000 Series Programmer's Manual

Command Groups
Command
Description
HORizontal:FAS Tframe:X ZEro:FRAme:
CH<x>?
Returns the time from the trigger to the
start of the specified frame on the specified
channel
HORizontal:
FAS Tframe:X ZEro:FRAme:
REF<x>?
Returns the t
ime from the trigger to the
start of the specified frame on the specified
reference
HORizontal:FAS Tframe:X ZEro:REF? Sets or returns the time from the trigger to the
trigger sam
ple on the reference waveform
HORizonta
l:FAS Tframe:XZEro:SELECTED:
CH<x>?
Sets or ret
urns the time from the trigger to
the trigger sample on the selected channel
HORizontal:FAS Tframe:X ZEro:SELECTED:
REF<x>?
Sets or returns the time from the trigger to
the trigger sample on the selected reference
waveform
HORizon
tal:MAIn?
Returns
the time per division of the main
time base
HORizontal[:MAIn]:DELay:MODe Sets or r eturns the main time base trigger
delay mode
HORizontal[:MAIn]:DELay:POSition Sets or returns the main time base position
when H
orizontal Delay M ode is turned off
HORiz
ontal[:MAIn]:DELay:TIMe
Sets o
r returns the main time base trigger
delay time
HORizontal:MAIn:INTERPRatio?
Retu
rns the main horizontal time base
interpolation ratio
HORizontal[:MAIn]:POSition Sets or returns the waveform horizontal
position on the display
HORizontal:MAIn:UNIts Sets or returns the units for the horizontal
tim
e base
HO
Rizontal:MAIn:UNIts:STRing
Se
ts or returns the units string for the
horizontal main time base trigger delay
HORizontal:MODE Sets or queries the horizontal mode. Auto
mode is the factory default
HORizontal:MODE:AUTO:LIMITrecordlen Sets or queries the record length limit used
by the auto horizontal mode
HORizontal:MODE:RECOrdlength Sets or queries the record length
HORizontal:MODE:SAMPLERate Sets or queries the sample rate
HORizontal:MODE:SCAle Sets or queries the horizontal scale
HORizontal:ROLL Sets or returns the horizontal roll mode status
HORizontal:TIME Stamp:CH<x>?
Returns the absolute trigger date and time
for the specified frame and waveform
HORizontal:TIMEStam p :REF <x>?
Returns the absolute trigger date and time
for FastFrame reference
2-26 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
