Tektronix MSO70000 Series Programmer's Manual

Commands Listed in Alphabetical Order
SEARCH:SEARCH
1:TRIGGER:A:PATTERN:WHEN:LES SLIMIT?
might return
:SEARCH:SEARCH1:TRIGGER:A :PATTERN:WHEN:LESSLIMIT 1 .0000E-9,
indicating the lesslimit time is set to 1 n s.
SEARCH:SEAR
CH<x>:TRIGger:A:PATtern:WHEn:MORELimit
This command sets or queries the time the pattern trigger morelimit test uses to
determines where to place a mark.
<x> is the search number.
Group
Search and Mark
Syntax
SEARCH:SEARCH<x>:TRIGger: A:PATtern:WHEn:MORELimit <NR3>
SEARCH:SEARCH<x>:TRIGger: A:PATtern:WHEn:MORELimit?
Related Commands
SEARCH:SEARCH<x>:TRIGger:A:PATtern:WHEn, SEARCH:SEARCH<x>:
TRIGger:A:PATtern:WHEn:LESSLimit
Arguments
<NR3> is the time in seconds.
Examples
SEARCH:SEARCH1:TRIGGER:A: PATTERN:WHEN:MORELIMIT 2. 0e-9 sets the
more limit time to 2 ns.
SEARCH:SEARCH1:TRIGGER:A: PATTERN:WHEN:MORELIMIT? might
return
:SEARCH:SEARCH1:TRIGGER:A:PA TTERN:WHEN:MORELIMIT
500.0000E-12
, indicating the more limit time is set to 500 ps.
SEARCH:SEARCH<x>:TRIGger:A:PULse:SOUrce
This command sets o r queries the source waveform for a pulse trigger search to
determine where to place a mark. <x> is the search number.
NOTE. This is the source for Glitch, Width, Runt, Timeout or Window searches.
Group
Search and Mark
Syntax
SEARCH:SEARCH<x>:TRIGger: A:PULse:SOUrce
{CH1|CH2|CH3|CH4|MATH1|MA TH2|MATH3|MATH4|REF1|REF2|REF3|REF4}
SEARCH:SEARCH<x>:TRIGger: A:PULse:SOUrce?
2-454 DPO7000, DPO70000/B and DSA7000/B Series Programmer Manual
